Crystek's CVCO55CC-4000-4000 VCO (voltage controlled oscillator) operates at 4,000 MHz with a control voltage range of 0.3 V~4.7 V. This VCO features a typical phase noise of -115 dBc/Hz at 10 kHz offset and has excellent linearity. Output power is typically 8 dBm.
Engineered and manufactured in the USA, the model CVCO55CC-4000-4000 is packaged in the industry-standard 0.5 in. x 0.5 in. SMD package. Input voltage is 8 V, with a typical current consumption of 40 mA. Pulling and Pushing are minimized to 1 MHz pk-pk and 0.2 MHz/V, respectively. Second harmonic suppression is -10 dBc typical.
The CVCO55CC-4000-4000 is ideal for use in applications such as digital radio equipment, fixed wireless access, satellite communications systems and base stations.
For pricing details, contact Crystek Corporation.
