Crystek Corporation's CVCO55FL-0355-0425 voltage controlled oscillator (VCO) operates from 355 to 425 MHz with a control voltage range of 0.5 V ~ 4.5 V. This VCO features a typical phase noise of -115 dBc/Hz at 10 kHz offset and has excellent linearity. Output power is typically +5 dBm.

Engineered and manufactured in the U.S., the model CVCO55FL-0355-0425 is packaged in the industry-standard 0.5 in. x 0.5 in. SMD package. Input voltage is 5 V, with a typ. current consumption of 30 mA. Pulling and Pushing are minimized to 0.3 MHz pk-pk and 0.8 MHz/V, respectively. Second harmonic suppression is -20 dBc typical.

The CVCO55FL-0355-0425 is ideal for use in applications such as digital radio equipment, fixed wireless access, satellite communications systems and base stations.
