Gowanda Electronics announces the introduction of several High Performance RF Surface Mount Inductor Series. Recent advancements in the company’s design technology and manufacturing capability deliver significant improvement–nearly 2x or more–in SRF and Current Ratings for these new inductors as compared to traditional molded designs with equivalent inductance. The first six series–CC4H1008, CF4H1008, CC4H1210, CF4H1210, CC4H1812 and CF4H1812–will be featured at the 2018 International Microwave Symposium (IMS) being held in Philadelphia, Pafrom June 12-14. Visit Gowanda’s booth #1735 for more information.
These series were developed to address market needs and industry trends calling for ever-increasing performance from RF SMT inductor components. These CC4H (ceramic core) and CF4H (ferrite core) series were designed for use in radio frequency applications in commercial, medical and military markets. That includes use in communication, guidance, security, radar and test & measurement applications.
The performance ranges provided by these six new wirewound series include inductance from 0.0082 to 1000 µH, Q min from 30 to 75, SRF MHz min from 2 to 4000, DCR ohms max from 0.060 to 30 and current rating mA DC from 96 to 2430. Operating temperature range is -55°C to +125°C for all series.
