Astronics Corporation, through its wholly owned subsidiary Astronics Test Systems, announced a breakthrough concept in PXI system development: the ATS-3100 PXI Integration Platform. The new ATS-3100 provides a starter “system-in-a-box” for engineers to rapidly create and configure new test, measurement, or other systems based on PXI, a versatile PC-based platform for measurement and automation systems.

“We’ve made it easier than ever before for system designers to create PXI-based solutions,” said Brian Price, vice president of Astronics Test Systems. “We’re eliminating the time wasted in configuring and debugging complex cabling or the custom integration of instruments. This new platform offers a streamlined, deployable solution that does all the hard work for you. Simply plug in your instruments, install your software and get going on producing your complete PXI system solution.”

“The core idea behind NI’s open software and modular hardware approach is flexibility that can be harnessed by the end user,“ said Reggie Rector, principal solution manager from National Instruments. “The ATS-3100 represents a highly integrated extension to the NI PXI platform to simplify the design and deployment of automated test systems.”

About the ATS-3100

The ATS-3100 PXI Integration Platform saves engineers time, complexity and non-recurring engineering (NRE) costs in developing next-generation PXI-based systems. Engineers can start with the basic set of technologies and focus time and energy on building final, polished solutions for any variety of applications such as testing, measuring, stimulating, computing and monitoring.

The ATS-3100 serves as a building block for desktop or rack-mount test systems in R&D and manufacturing environments. Containing all of the elements needed to jump start system development, the ATS-3100 features:

  • 18-slot hybrid PXI/PXI Express chassis
  • The latest NI backplane technology
  • Reconfigurable front and rear panels for customer defined I/O for a variety of applications
  • Internal cable and connection management
  • Large touchscreen display
  • Controller
  • Mechanical packaging
  • Compatibility with TestStand or LabVIEW software from NI

The ATS-3100 is a modular system, and engineers can integrate instruments from any vendor or specify instruments from Astronics Test Systems in their configuration. Available PXI instruments from Astronics include a digitizer, pulse pattern generator, waveform generator, frequency time and interval counter, rubidium and digital test instrument. The configurable platform also “future proofs” finished test systems with the ability to upgrade instruments and software at any time.

In addition to a standalone package, Astronics Test Systems will also offer the ATS-3100 PXI Integration Platform as part of a turnkey solution in which Astronics can provide the instruments and customization to create an entire system to customer requirements.

Astronics Test Systems will display the new ATS-3100 PXI Integration Platform for the first time at NIWeek in Austin, Texas, from May 22-25, 2017. For complete product details and to request a quote on the new ATS-3100, visit
