Hirose has launched a 1.0 mm coaxial connector that complies with the IEEE Std. 287 and supports frequencies up to 110 GHz. Featuring a compression-mount center contact, the 1.0 mm Series coaxial connector supports varying PCB thicknesses from under 1 mm to several mm — providing greater design flexibility. Eliminating the need for soldering, the 1.0 mm Series also features a screw (threaded) mount to reduce mounting complexity.
“The 1.0 mm Series coaxial connector provides superior high frequency performance with reliable mechanical stability,” said Pete Lais, assistant vice president of product management for Hirose Electric Americas. “The 1.0 mm Series is ideal for applications that demand high signal integrity, low insertion loss and reliable mechanical performance at extremely high frequencies.”
The coaxial connector delivers excellent high frequency performance and has low voltage standing wave ratios (VSWR) of:
- 1.8 max. (0 to 67 GHz)
- 1.9 max. (67 to 110 GHz)
The 1.0 mm Series is commonly used in test and measurement systems, as well as high frequency sensing and communication applications.
For additional information about the 1.0 Series coaxial connector, visit: https://www.hirose.com/en/product/series/1.0mm
