Anritsu Corporation, in collaboration with dSPACE, has developed an advanced digital twin simulation environment designed to provide improved protection for vulnerable road users (VRUs). At 5GAA, October 23-27, 2023, in Detroit, the two companies will demonstrate a road safety use case using the C-V2X 5G network for cooperative communications.

VRU include pedestrians, bicycles, among others and there is growing global interest in using C-V2X technologies to prevent accidents with vehicles. VRU protection is actively being developed for roads and intersections to ensure safety and improve accident prevention. As a technology to support this, there has been direct detection of VRU by installing advanced driver assistance systems sensors in vehicles.

The international organization 5GAA has been investigating accident prevention methods by the use of 5G-network-based communication, which is based on cooperative communications to and from VRUs. Unlike in-vehicle-based methods, it is expected that protection in blind spots — such as outside the effective detection range of vehicle-mounted sensors and building shadows — will also be possible via 5G network communication. To achieve this, the 5G communication to cooperative VRUs must be reliable, and the evaluation of quality of service management and fault tolerance at the IP layer is a critical factor.

The demo solution provides a digital twin environment for real-world scenarios, so VRU protection testing can be started virtually when features are not yet available on the actual vehicle. This demonstration has attracted the attention of automakers, auto parts suppliers and mobile network operators. Anritsu will continue to develop this solution to improve the protection of VRUs and contribute to the development of smart cities by setting up an advanced simulation environment using digital twins.

“Today almost 40 percent of fatalities on the road are people outside the vehicles — pedestrians, cyclists, road workers, children and others. It is a priority for the 5GAA members to leverage C-V2X technologies to protect these VRUs. This digital twin technology demonstration shows how C-V2X communications can offer this great societal opportunity,” stated Maxime Flament, CTO of 5GAA.

Demonstration Overview

1.   dSPACE's PC-based simulator is a tool that simulates the integration of environmental, infrastructure, sensor and vehicle information using a PC. In this demonstration, VRU protection simulation is performed by reproducing the University of Michigan's automotive test course "M City" used at the 5GAA meeting week, together with smart cameras and different road users.

2.   V2X data messages generated by communication devices such as smartphones carried by vulnerable road users, including cyclists and pedestrians, as well as sensor information from intersection cameras, are transmitted to an OEM application that displays VRU protection results on the vehicle side via 5G communication using Anritsu’s MT8000A 5G base station simulator

Product Details

Base Station Simulator Radio Communication Test Station MT8000A

The test platform provides network simulation compatible with 5G radio access technology and provides a development evaluation and certification test environment for automotive use cases such as Telematics, Infotainment and V2X.
