Pasternack, an Infinite Electronics brand, has released a new line of waveguide frequency multipliers covering 26.5 to 110 GHz, including popular mmWave waveguide bands: Ka, U, V, E and W.

Pasternack now offers an innovative series of in-stock, waveguide frequency multipliers for 5G, test and measurement, mobile and satellite communications, radar systems, research and development and weather and earth observation applications.

These waveguide frequency multipliers feature output power from 10 to 20 dBm and DC voltages from 6 to 15 Vdc. They provide input frequency multiplication ranges from 2x to 6x the output, and support female SMA connectors.

The new line of waveguide frequency multipliers support highly efficient performance in a smaller package size. They’re designed with GaAs and GaN MMIC semiconductor technology for lower conversion loss.

Pasternack’s frequency multipliers are rugged and compact with military-grade, gold-plated aluminum waveguide package designs. They also guarantee all-weather performance with operational temperatures from -10°C to +60°C, exposure to 95 percent relative humidity and an altitude of 10,000 feet.

“Designers will find these broadband frequency multipliers useful in developing lower frequency signals with lower power and less expensive devices in a microwave frequency band, and then multiplying to generate an output signal to a desired mmWave frequency. Models are available in-stock with no minimum order quantity,” said Tim Galla, product line manager.

Pasternack’s new waveguide frequency multipliers are in-stock and ready for immediate shipment with no minimum order quantity.
