High speed data transmission and requirements for low latency demand implementations of narrow RF multi-channel designs and low interference with coexisting bands, in accordance with Wi-Fi 6E and Wi-Fi 7/IEEE802.11ax standards.

Johanson Technology announces a tighter rejection 5.5 GHz bandpass filter and a dual-band rooftop Wi-Fi 5 and Wi-Fi 6E, 6.1 GHz, bandpass filter supporting Wi-Fi 5.5 F and Wi-Fi 6E and Wi-Fi 7 GHz bands.

The 5.5G GHz bandpass filter, EIA 1812 (4.5 x 3.2 metric) and operating frequencies of 5.1 GHz through 5.8 GHz (part number 5500BP44A0700), offers a 50 dB attenuation with a coexisting 6 GHz Wi-Fi band.

The 6.1 GHz SMD filter, EIA 0603 (1.6 x 0.8 metric) and operating frequencies of 5.17 GHz through 7.125 GHz (part number 6100BP14A1995), offers a 2 GHz bandwidth solution with 0.9 dB insertion loss suitable for highest antenna power transfer demands.
