Skyworks introduced the SKY68031-11, the industry’s smallest, multi-band RF front-end (RFFE) module for licensed, low-power, wide-area network (LTE-M/NB-IoT) applications including asset tracking, health and fitness wearables, smart metering and industrial monitoring. This module integrates the entire RFFE necessary for a cellular IoT radio operating in low-band (5, 8, 12, 13, 14, 17, 18, 19, 20, 26, 28, 85) and mid-band (1, 2, 3, 4, 25, 39, 66, 70) frequencies. The FEM monolithically integrates a broadband power amplifier, transmit harmonic filters, antenna switch and MIPI RFFE controller, all in a compact 3 x 3 mm package.

 SKY68031-11 Features

  • Global Coverage: Up to 20 frequency bands enabling same FEM and PCB design to be used anytime, anywhere
  • Turnkey Solution: PA, harmonic filters, antenna switch and matching co-designed hand-in-glove with package, requiring minimal effort to use
  • Small Size: 9 mm2 package enabling significant size reduction and usability in system-in-packages
  • Smart Biasing: Up to 6 different bias conditions can be pre-defined and programmed through MIPI interface to optimize PA performance and reduce current consumption.

SKY68031-11 Specifications
Frequency (MHz): 698 to 915, 1695 to 1980
Description: Low Profile, Multi-Band Massive IoT Front-end Module
Output Power (dBm): 23.5
Supply Voltage (V): 2.85 to 4.5
Package (mm): 3 x 3 x 0.7, 24-Pad
