Modelithics is pleased to broadcast that its premier product, the Modelithics COMPLETE Library, has surpassed more than 22,000 components for over 775 models from 70 of today’s top vendors.

Since Modelithics was founded in 2001, the company has continually increased the number of library models each year to meet the evolving needs and demands of today’s designers involved with PCB-based RF and microwave circuit design. Now, with models for more than 22,000 components, Modelithics has reached a new milestone that provides designers with access to an exceptional number of models for applications across the board. Larry Dunleavy, president and CEO of Modelithics, stated, “Our Product Manager Eric told me a couple years ago his goal was 20K parts represented in 2020, I liked the goal but love the over-achievement even more. To Eric and the team, I say ‘Fantastic!' To our partners and customers, we say thank you for your support and let’s keep growing together!”

The Modelithics COMPLETE Library includes Microwave Global Models™ for capacitors, inductors and resistors. A Microwave Global Model covers a full range of part values for a vendor component series, making them well-suited when tuning or optimization is needed. These models can be used to design filters, matching networks and many other circuits for all types of applications. In addition to part-value scalability, Microwave Global Model scale with respect to substrates and solder pads. Also included in the Modelithics COMPLETE Library are nonlinear transistor and diode models as well as linear and non-linear models for system level components like amplifiers, filters, attenuators and couplers. These models offer features like substrate scalability, bias and temperature dependence, noise prediction and more.

Modelithics models are currently available for Keysight Technologies’ PathWave Advanced Design System, Keysight Technologies’ PathWave RF Synthesis (Genesys), Cadence® AWR Design Environment®, Ansys® HFSS™, Sonnet® Suites and Cadence Virtuoso Spectre RF.
