Ranatec, a part of the Qamcom group and supplier of specialized test and measurement equipment for RF and microwave applications, announced the release of the Ranatec Big RF Shield Box. The lightweight aluminum device is designed and highly suitable for testing of mobile base stations, point-to-point microwave links (P2P, PTP) or any other large test setup.

The 1.2 x 0.7-meter area is easy to access from the top and incudes a powerful cooling fan, designed for up to 2000 W generated heat inside the box. The Ranatec RI 189 Big RF Shield Box supports a wide variety of interfaces including 10 Gbit LAN, USB 3.0, HDMI, SMA, 230 VAC, 24 VDC.

“The new RF testing big box is uniquely lightweight and portable, confirmed Magnus Kilian, CEO at Ranatec. We have received keen interest in the new test device which has already been delivered to a large global semiconductor company.”

Key Features

  • 1.2 x 0.7 x 0.6 meters
  • 70 dB between 1 and 10 GHz
  • Can fit under a work bench or table
  • Portable, lightweight aluminum design
  • Ventilation designed for up to 2000 W heat generation inside the box
  • HDMI- USB- LAN- AC- DC- and SMA-interface.

Ranatec Quality Assurance

Ranatec is ISO9001:2015 certified and offers specialist services within eight defined domains to a global customer base including the world’s leading electronics manufacturers.
