Atlanta Micro announces the product release of a DC to 18 GHz single pole, six-throw (SP6T) switch, part number AM6015.

 AM6015 provides low insertion loss, flat frequency response, and high isolation and operates from a +3.3 to +5.0 V supply with positive logic control.

 Fig 1

 The device is packaged in a 4-mm QFN and operates over the -40C to +85C temperature range. To view this product online please click: (
