Mercury Systems, Inc. announced that systems using ANSI/VITA 48.7 Air Flow-By™ standard cooling technology have passed flight tests in multiple manned and unmanned airborne platforms, some in their final mission configuration, thereby achieving technology readiness level 8 (TRL-8). Mercury holds a patent on one implementation approach of that standard, and has revised the licensing fees under the patent to be zero cost.

Mercury Systems developed Air Flow-By cooling technology as an improvement to its finely managed air cooling, the original air flow-through (AFT) technology it developed back in 2003. Air Flow-By cooling technology is the most efficient solution on the market to achieve a sealed environment that tolerates cooling with air that may contain contaminants. Unlike today’s AFT technology that merely adds an airflow heat exchanger to the primary side surface of a printed wiring board (PWB), Air Flow-By solutions cool both sides of the PWB by encapsulating the PWB in a heat exchanger shell such that air flows across both sides of the module for maximum cooling efficiency. The heat exchanger shell creates a sealed environment that protects against airborne contaminants, electromagnetic interference (EMI), electrostatic discharge (ESD) and provides an extra layer of physical security. Even with the increased protection and cooling capacity, Air Flow-By solutions maintain the standard one-inch pitch to avoid a 33 percent reduction in board count found in AFT implementations that may require the module width to grow to 1.5-inch pitch. Now, Air Flow-by technology also has a cost advantage with its zero-cost licensing.

“Air Flow-By technology has proven to be more effective at cooling mission electronics than competing technology such as air-flow through,” said Richard Jaenicke, director of strategic alliances at Mercury Systems. “With the achievement of TRL-8, we want to remove any barriers to the adoption of Air Flow-By technology by all industry participants and have reduced the license fees to zero cost.”

Air Flow-By cooling also compares extremely favorably to conduction cooling, which is the legacy rugged cooling technology. For example, on power-hungry processor modules, Air Flow-By cooling enables both increased processor frequency and mean time between failures (MTBF) while decreasing overall weight. Typical improvements seen include:

  • 25 percent reduction in processor temperature for dual Intel® Xeon® processors,
  • 33 percent increase in processor frequency at that reduced temperature,
  • 5x increase in MTBF,
  • 25 percent reduction in weight of the processor module.

Mercury’s US patent 9,389,653 B2 for Air Flow-By Cooling Technology and Air Flow-By Circuit Board Modules has always been available to be licensed to all VITA members under standard Fair, Reasonable and Non-Discriminatory (FRAND) licensing terms as part of the normal VITA standards process. The announcement reduces the patent licensing fees to zero cost under Mercury’s patent licensing terms that allow licensees to use claims under this patent that may be essential to create an implementation compliant with the ANSI/VITA 48.7 standard, and it extends those terms beyond VITA members to all industry participants. Licensees just need to sign Mercury’s patent license agreement to use the claims under this patent.

For more information about Air Flow-By cooling technology, visit www.mrcy.com/cool or contact Mercury at (866) 627-6951 or info@mrcy.com.
