TMYTEK announced the launch of their newest range of products, Development UD Board that are designed to elevate user experience and meet diverse needs.

The Development UD Board offers the ability to expand the frequency range of testing instruments to 24 to 30 GHz, all at an affordable price.

TMYTEK’s UDBoard, a versatile product designed for seamless communication. It offers half-duplex  capability with Tx single-sideband up-conversion and Rx image-reject down-conversion. Choose from  high or low side LO and benefit from the included frequency multiplier for easy integration with external  PLLs. Enjoy 11.5 dB conversion gain in transmit and 8 dB gain with 12 dBm IIP3 in receive mode. Effortlessly switch between modes using the slide switch for a superior communication experience.

TMYTEK’s signal generator presents itself as a configurable source, well-suited for integration into  various RF front-end systems. Offering a spectrum of output options ranging from 180 MHz to 18 GHz, with frequency resolutions set at 10 kHz intervals and a selection of 12 distinct output power level facilitated by dual synchronized sources. This equipment showcases commendable phase noise characteristics, extensive bandwidth coverage and an exceptional level of adaptability.
