Analog Devices, Inc. (ADI) introduced a 9 kHz to 7 GHz directional bridge and dual RMS RF power detector that simultaneously measures forward and reverse RMS power levels in a signal path, along with return loss.

The ADL5920 detector is a change to conventional approaches, integrating a directional bridge-based coupler that results in an industry leading level of integration and bandwidth. For space-critical applications, the ADL5920 integrates the coupling or sensing function with the detection function and provides an output that can directly drive a precision analog-to-digital converter (ADC). For wideband operation or for frequency variants, the ADL5920 detector eliminates the need to choose a different directional coupler for each frequency. This integrated, wideband device supports smaller form factors and enables faster product time-to-market.

ADL5920 Product Highlights

  • Allows for coupled power measurements down to 9 kHz
  • Maximum input signal: +30 dBm with handling capability for open and shorted loads
  • Requires a 5 V supply and draws 150 mA
  • Supplied in a 32-lead, 5 mm x 5 mm LFCSP, for the operating temperature range of −40°C to +85°C.

Pricing and Availability

Product Sample Availability Full Production

Price Each Per 1,000

ADL5920 Now December 2017 $14.50 5 mm x 5 mm LFCSP
